| Maximum Thread Diameter | 1-1/4" |
| Depth of Die Pockets | 6-1/8" |
| Strokes Per Minute | Approx. 40 |
| Length of Moving Die | 20" |
| Length of Stationary Die | 19" |
| Distance Between Top of Die Block & Bottom of Tie Rod | 8-1/2" |
| Maximum Length of Work Piece if End of Shank is at the Bottom of Die Pocket | 14-1/2" |
| Electrics | 30 HP, 890 RPM, 230/460V, 3 Phase |
| Approx. Weight | 24,000 lbs |
| Equipped With | With Adjustable Pitman, Gravity Lubrication, V-Grooved Flywheel, 6-Pusher Bolts and 2 Pull Back Bolts on Die Block, Recirculating Coolant (Requires Reservoir) |
